| Size: | |
|---|---|
| Pipeline expansion stroke : | |
| Spray repair rate : | |
| Feed tank capacity : | |
| Spraying method: | |
| Quantity: | |
SM08
INNOVAKE
SM08
Extreme Temperature Resistance
Operates continuously at 1,200°C with specialized refractory components
High-temperature seals and insulation ensure reliable performance
Precision Manipulation
12m telescopic lance: Reaches hard-to-access areas with 0.25m/s extension speed
±170° lance rotation: 45°/s angular velocity for pinpoint targeting
High-Speed Material Delivery
80-120kg/min gunning rate: Faster than manual methods
Semi-dry process: Reduces water usage while ensuring material adhesion
Mobility & Stability
Tracked chassis: 4m turning radius for confined spaces
26° gradeability: Negotiates uneven shop floors
Parameter | Wheel-Mounted Model | Tracked Model |
Weight | 6.2 tons | 8 tons |
Dimensions (L×W×H) | 2.9×1.5×2.7m | 3.2×2×2.6m |
Power Source | 8.5kW/2200RPM diesel | 32kW/2000RPM diesel |
Nozzle Height | 1,500mm | 1,750mm |
Material Rate | 60-100kg/min | 80-120kg/min |
Grain Size | ≤15mm | ≤15mm |
Lance Extension | 12m (0.25m/s speed) | 12m (0.25m/s speed) |
Lance Rotation | ±170° (45°/s) | ±170° (45°/s) |
Lance Swing | ±170° (12°/s) | ±110° (12°/s) |
Lance Tilt | ±20° (4°/s) | Down 20°/Up 12° (4°/s) |
Hopper Capacity | 1,000kg | 0.8m³ |
Air Pressure | 0.45-0.6MPa | 0.6-0.7MPa |
Dual Control Modes: Wireless remote + cabin operation
Modular Design: Quick tool changes for different gunning materials
Intelligent Monitoring: Real-time pressure/temperature sensors
Safety Systems: Emergency stop, flame-retardant hoses
Converter lining erosion repair
BOF slag line maintenance
Ladle refractory patching
High-temperature furnace rebuilding
✅ 50% Faster Repairs: Reduces downtime compared to traditional methods
✅ Cost Efficiency: Minimizes material waste and labor requirements
✅ Safety Upgrade: Remote operation reduces personnel exposure
✅ Customization: Adjustable parameters for different refractory types
